Optek Epi-Trino
Technical data
| Head | Trinocular, rotating (inclined 30°) |
|---|---|
| Stage | 210 × 120 mm, travel 70 × 50 mm |
| Nosepiece | Five-position reversed nosepiece |
| Diaphragm | Iris with filter holder |
| Condenser | Abbe, N.A. 1.25, with centring mechanism |
Description
Technical data:
- Wide-field eyepieces WF10x (22 mm)
- Plan achromatic INFINITY objectives:
PL 4x/0.10, 17.9 mm
PL 10x/0.25 + 20x, 8.8 mm
PL 40x/0.65 (spring-loaded), 0.56 mm
PL 100x/1.25, 0.33 mm
- Head: trinocular, rotating (inclined 30°)
- Stage: 210 × 120 mm, travel 70 × 50 mm
- Nosepiece: five-position, reversed
- Diaphragm: iris with a filter holder
- Condenser: Abbe N.A. 1.25 with a centring mechanism
- Illumination: transmitted 6 V 20 W halogen with adjustable intensity — EPI fluorescence 110 V/220 V, 100 W mercury lamp/DC, selectable wavelength (UV, V, B, G)
- CCD video path (options):
0.4x CCD camera adapter
0.4x adjustable CCD camera adapter
CCD camera adapter
0.5x CCD camera adapter with beam splitter
CCD camera video path; Canon A-series digital camera above the 630 (at extra cost)
