Optek Labor XP-PL
Technical data
| Head | CF binocular, inclined 30°, rotates 360°, interpupillary distance 55–75 mm, left-hand dioptre adjustment ±5 |
|---|---|
| Eyepiece | WF 10x/22 mm, 10x with graticule, 10x with crosshair |
| Objective (magnification / N.A. / W.D.) | Stress-Free Infinity Plan |
| Nosepiece | Centrable reversed nosepiece, five sockets |
| Magnification | 40x - 630x |
| Zoom | - |
| Working distance | - |
| Stage | Rotates through 360°, 172 mm diameter, upper stage position lock, adjustable movement resistance |
| Filter | - |
| Condenser | Floating Abbe N.A. 1.25, iris diaphragm, height adjustment |
| Focusing system | Ergonomic coaxial coarse/fine focus knob on both sides, graduation 0.002 mm |
| Light source | 6 V / 30 W halogen, built-in power supply, continuously adjustable intensity |
| Microscopy method | Polarisation |
| Measurement | - |
| Dimensions | - |
| Weight | 5 kg |
| Stress-Free Plan Infinity | 10 0x (S,O) |
Description
Head: CF binocular, inclined 30°, rotates 360°, interpupillary distance 55–75 mm, left-hand dioptre adjustment ±5
Eyepiece: WF 10x/22 mm, 10x with graticule, 10x with crosshair
Objective (magnification / N.A. / W.D.): Stress-Free Infinity Plan
* 4x
* 10x
* 25x
* 40x (S)
* 63x (S)
Nosepiece: centrable reversed five sockets
Magnification: 40x – 630x
Zoom: -
Working distance: -
Stage: rotates through 360°, 172 mm diameter, upper stage position lock, adjustable movement resistance
Filter: -
Condenser: floating Abbe N.A. 1.25, iris diaphragm, height adjustment
Focusing system: ergonomic coaxial coarse/fine focus knob on both sides, graduation 0.002 mm
Light source: 6 V / 30 W halogen, built-in power supply, continuously adjustable intensity
Microscopy method: polarisation
Set of wave plates:
* Gypsum 1λ
* Mica 1/4λ
* Quartz wedge
Measurement: -
Dimensions: -
Weight: 5 kg
Optional accessories:
Eyepiece: WF16x, WF20x, P16x
Objective:
Stress-Free Plan Infinity: 100x(S, O)
Light source: SMD module LED
