SCMOS03000KPA
Technical data
| Sensor | Aptina CMOS(Color) |
|---|---|
| Scanning | Progressive |
| Resolution | 2048 x 1536 |
| Sensor size | 1/2.7“ (4.506mm(H) x 3.379mm(V), Diagonal 5.632mm) |
| Dynamic range (DR) | 6 1dB |
| A/D converter | 12-bit, 8-Bit R.G.B to PC |
| S/N gain | 43 dB |
| Spectral range | 380-650nm (with IR-filter) |
| FPS | 3fps @2048 x 1536, 5fps @1600 x 1200, 7.5fps @1280 x 1024, 30fps @Other Resolutions |
| Binning | - |
| Exposure | Electronic Rolling Snap (ERS), ROI automatic & manual |
| Colour rendering technique | - |
| White balance | Automatic / manual |
| Capture / control via API | Native C/C++, DirectShow, Twain |
| Capture type | Still images and video |
| Interface / power | USB 2.0 |
| Software | ToupCam PL |
| Mount | 23 mm tube |
| Drivers | Windows (all x86 and x64 editions), Linux, Mac OS X |
Description
Sensor: Aptina CMOS (colour)
Scanning: Progressive
Resolution: 2048 × 1536
Sensor size: 1/2.7" (4.506 mm (H) × 3.379 mm (V), diagonal 5.632 mm)
Pixel size: 2.2 µm × 2.2 µm
Sensitivity: 1.0 V/lux-sec (550 nm)
Dynamic range (DR): 61 dB
A/D converter: 12-bit, 8-bit R.G.B to PC
S/N gain: 43dB
Spectral range: 380–650 nm (with IR filter)
FPS: 3 fps @ 2048 × 1536, 5 fps @ 1600 × 1200, 7.5 fps @ 1280 × 1024, 30 fps at other resolutions
Binning: -
Exposure: Electronic Rolling Snap (ERS), ROI automatic & manual
Colour rendering technique: -
White balance: Automatic / manual
Capture / control via API: Native C/C++, DirectShow, Twain
Capture type: Still images and video
Interface / power: USB 2.0
Software: ToupCam PL
Mount: 23 mm tube
Drivers: Windows (all x86 and x64 editions), Linux, Mac OS X
