XTL II
Technical data
| Head | Binocular inclined at 45°, interpupillary distance 54–76 mm, right-hand dioptre correction ±5 |
|---|---|
| Eyepieces | 10 x |
| Objectives | 2x, 4x |
| Magnification | Stepped 20x, 40x |
| Working distance | 57 mm |
| Working height | 110 mm |
| Illumination | None (daylight) |
| Stage | Plain stage with slide clips |
Description
Technical data:
head: binocular inclined at 45°, interpupillary distance 54–76 mm, right-hand dioptre correction ±5
eyepieces: 10x
objectives: 2x, 4x
magnification: stepped 20x, 40x
working distance: 57 mm
working height: 110 mm
illumination: none (daylight)
stage: plain, with clips to hold the specimen
Optional extras:
eyepieces: 5x, 15x, 20x
