XTL III LED
Technical data
| Head | Binocular inclined at 45°, interpupillary distance 54–76 mm, right-hand dioptre correction ±5 |
|---|---|
| Eyepieces | 10x/20mm |
| Objectives | 2x, 4x |
| Magnification | Stepped 20x, 40x |
| 2x objective | 50 mm |
| 4x objective | 50 mm |
| Working height | 110 mm |
| Focus adjustment | Knobs on both sides |
| Stage | Plain stage with slide clips |
| Illumination | DIA and EPI LED |
| Interchangeable plates | Matt, black and white |
| Power supply | Rechargeable batteries and mains adapter included |
Description
Technical data:
head: binocular inclined at 45°, interpupillary distance 54–76 mm, right-hand dioptre correction ±5
eyepieces: 10x/20 mm
objectives: 2x, 4x
magnification: stepped 20x, 40x
working distance:
* 2x objective: 50 mm
* 4x objective: 50 mm
field of view:
* 2x objective: 9 mm
* 4x objective: 4.5 mm
working height: 110 mm
Focus adjustment: knobs on both sides
stage: plain, with clips to hold the specimen
illumination: DIA and EPI LED
interchangeable plates: matt, black and white
Power: Rechargeable batteries and mains adapter included
Optional extras:
eyepieces: 5x, 15x, 20x
A dust cover for the microscope is included.
The microscope ships in a carton with a polystyrene insert.
